Clippard LVA-3 HD LIMIT VLV,3WAY,NC

$75.92 $64.53

SKU: CP17338C Categories: , Tags: , , ,

Clippard LVA-3 HD LIMIT VLV,3WAY,NC

STOCK STATUS: 5

i Notice: Item(s) that qualify will ship out the same day as long as the order is received before 1:00 PM EST (Monday-Friday), orders received after 1:00PM are not guaranteed same day shipment. Orders received after 1:00 PM EST on Friday will ship the following Monday. If you have questions regarding stock availability please call us at 1-800-277-4466 before placing an order.
In Stock: The item is in stock at our warehouse and qualifies to ship out the same day as long as the order is placed before 1:00 PM EST.
Factory Stock: The item is available from one of our support factory warehouses. Most items will ship the same day as long as the item is in stock and the order is received before the 1:00 PM EST. If no stock is shown that means the factory could be out of stock, please call for the lead time.
Call to Check Availability: The item is listed as available to order from one of our supporting warehouses, STOCK IS NOT GUARANTEED. If a rush item is needed, please call and check item lead time before placing an order.
Out of Stock: Item is discontinued, back-ordered, or limited stock is available. Please call to check stock availability.

Description

Heavy Duty Limit Valve, 3-Way, Normally-Closed
For convenience in porting away exhaust air or attaching muffler. It should not be restricted exhaust port is not used on 2- ways.
Air Flow 280 l/min @ 50 psig; 540 l/min @ 100 psig
Force 3″ / lbs.
Input PSI 300 psig
Medium Air
Mount Four 13/64″ dia. mounting holes provided in valve body for use with #10 screw, or for tapping 1/4-20.
Ports 1/8″ NPT
Stem Travel 50?
Temperature Range 32 to 230?F
Travel Arc 0-23? Off – 23-50? On
Weight 0.7300

Details

Weight 2 lbs
Dimensions 5 × 5 × 5 in
